Technical Specifications Input: LVDT; Output: 4–20 mA; Supply: 24 V DC ±10%; Accuracy: ±0.1% FS; Temperature drift: < 0.005% per °C; Operating temperature: -10 °C to +70 °C; Enclosure: IP40.
Functional Features High-precision synchronous demodulation; low-drift design; precision zero/span adjustment; sensor cable compensation; self-diagnosis.
Application Scenarios Precision servo valve feedback, turbine governor oil motor stroke, high-precision test bench displacement measurement, metrology-grade position monitoring.
Performance Parameters Linearity: ±0.1% FS; Repeatability: ±0.05% FS; Temperature drift: < 0.005% per °C; Response time: < 10 ms.
Material Composition Metal shielded enclosure; precision analog circuit; low-drift components; shielded terminals.
Structural Characteristics DIN rail mountable; front precision adjustment potentiometers; metal shielded body.
Working Principle Uses synchronous demodulation and low-drift precision components to demodulate and convert the LVDT signal, outputting a highly stable proportional current signal.
Installation Requirements Install in temperature-stable environment; use low-noise shielded cable; calibrate after warm-up; keep away from strong EMI.
