Technical Specifications Input: 3-wire LVDT, custom range; Output: 4–20 mA; Supply: 24 V DC ±10%; Accuracy: ±0.2% FS; Operating temperature: -40 °C to +80 °C; Enclosure: IP40; Factory pre-calibrated.
Functional Features Factory calibrated custom range; high-precision displacement conversion; field-adjustable zero/span; sensor fault detection.
Application Scenarios Dedicated valve position feedback, custom actuator stroke monitoring, non-standard displacement sensing systems, import equipment spare replacement.
Performance Parameters Linearity: ±0.2% FS; Temperature drift: < 0.008% per °C; Repeatability: ±0.1% FS.
Material Composition Flame-retardant housing; precision analog circuit; calibration-matched excitation stage; sealed terminals.
Structural Characteristics DIN rail mountable; front adjustment potentiometers; status LED; factory calibration label.
Working Principle Provides matched excitation and demodulation for the custom-range LVDT, accurately converts displacement to standard 4–20 mA signal, with full range calibration completed at factory.
