Technical Specifications Supply: 24 V DC ±10%; control input: 4–20 mA; stroke: 25 mm nominal; output force: 120 N maximum; full stroke time: 70 ms; position feedback: integrated; operating temp: -40 °C to +85 °C; IP65.
Functional Features Closed-loop position control; brushless drive; zero/span adjustment; overload protection; low friction design.
Application Scenarios Diesel engine fuel rack control, gas valve positioning, linear governor actuation, process valve control.
Performance Parameters Position repeatability: ±0.1 mm; linearity: ±0.5% full stroke; step time: < 70 ms.
Material Composition Aluminum housing; brushless motor; ball screw drive; position sensor; stainless steel output rod.
Structural Characteristics Linear output rod with clevis; front mounting flange; sealed cable entry; integrated control electronics.
Working Principle Converts rotary motor motion to linear via ball screw, uses internal position feedback to maintain precise target position per command signal.
Installation Requirements Mount via flange; connect output rod to linkage; align linkage to avoid side load; calibrate stroke.
Usage Notes Lubricate per service interval; protect rod from contamination; avoid side loads on output rod.
