Technical Specifications Supply: 24 V DC ±10%; 2 channels; input: 4–20 mA per channel; output: 0–2 A per channel; dither: per-channel adjustable; operating temp: -40 °C to +85 °C; IP40.
Functional Features Dual independent analog control loops; per-channel zero/span/dither adjustment; short-circuit protection per channel; coil fault detection.
Application Scenarios Dual-valve turbine control, dual-actuator fuel systems, multi-valve hydraulic manifolds.
Performance Parameters Current accuracy: ±0.5% FSO per channel; channel isolation: 800 V AC; response time: < 15 ms.
Material Composition Metal housing; dual analog control stages; power output circuits; insulated terminals.
Structural Characteristics DIN rail mount; front channel status LEDs; rear multi-pin terminal block.
Working Principle Each channel independently conditions the input signal and regulates output current to its respective solenoid valve.
Installation Requirements Mount on DIN rail; wire each valve separately; calibrate each channel independently.
Usage Notes Label channels to avoid miswiring; test each channel separately during commissioning.
