Technical Specifications Voltage input: 120–240 V AC, 50/60 Hz; output: 4–20 mA bias signal, SPDT sync permit relay; phase window: ±2° to ±15° adjustable; frequency matching: ±0.05 Hz accuracy; supply: 24 V DC; operating temperature: -20 °C to +70 °C; enclosure: IP40.
Functional Features Solid-state synchronization; automatic frequency bias output; voltage matching; adjustable phase window; dead bus detection; breaker time compensation.
Application Scenarios Automatic generator paralleling, unattended standby generator systems, multi-generator power plants, microgrid synchronization.
Performance Parameters Phase matching accuracy: ±0.5°; frequency accuracy: ±0.03 Hz; synchronization time: < 5 cycles typical; relay output time: < 15 ms.
Material Composition ABS plastic housing, microprocessor control circuit, voltage sensing transformers, output relay, terminal block connections.
Structural Characteristics Panel mount module; front status LEDs and adjustment controls; rear terminal block for all wiring; mounting ears.
