Technical Specifications Input voltage: 120–240 V AC, 50/60 Hz; output: 0–120 V DC, 10 A continuous; control input: 4–20 mA analog; current limit: 12 A adjustable; operating temperature: -20 °C to +75 °C; enclosure: IP20; conversion topology: phase-controlled SCR.
Functional Features Solid-state excitation power control; analog current control input; adjustable current limiting; overvoltage protection; short-circuit protection; fast current response.
Application Scenarios Generator excitation power stage, AVR DC output stage, small to medium generator excitation, industrial generator voltage regulation.
Performance Parameters Current regulation accuracy: ±2% full scale; response time: < 5 ms; current ripple: < 10% peak-to-peak; efficiency: > 90% at full load.
Material Composition Steel chassis, silicon controlled rectifiers (SCR), current sense transformer, filter capacitors, heat sink assembly.
Structural Characteristics Chassis mount module; integral finned heat sink; front terminal block for input, output and control; status indicator LEDs.
Working Principle The module receives a 4–20 mA control signal and varies the firing angle of silicon controlled rectifiers to regulate the DC output current supplied to the generator field winding, providing controlled excitation for voltage regulation.
