Technical Specifications Supply voltage: 24 V DC ±10%; control input: 4–20 mA; output torque: 55 lb-ft nominal; rotational stroke: 90°; full stroke time: 250 ms; position feedback: integrated LVDT; operating temperature: -40 °C to +85 °C; enclosure: IP66; duty cycle: continuous S1.
Functional Features Brushless DC motor drive; closed-loop position control; integral LVDT position feedback; zero and span adjustment; overload and over-temperature protection; vibration-resistant design.
Application Scenarios Large engine fuel control, gas turbine inlet guide vane actuation, industrial burner air control, large valve positioning, engine governor actuation.
Performance Parameters Position repeatability: ±0.1% of stroke; linearity: ±0.5% full scale; step response time: < 200 ms for 90°; vibration resistance: 15 g peak.
Material Composition Cast aluminum housing, brushless DC motor, planetary gear train, LVDT position sensor, steel output shaft, fluorosilicone shaft seals.
Structural Characteristics Rotary output shaft with keyway; four-bolt mounting flange; integrated control electronics; sealed cable gland entry; heavy-duty bearing assembly.
