The Rockwell Automation 1786-TPYR Thermocouple Input Module delivers high-precision temperature measurement for industrial process control. Engineered for seamless integration with Allen-Bradley ControlLogix systems, this 8-channel module ensures accurate thermal monitoring in critical manufacturing environments like chemical processing, metal fabrication, and energy production.
| Parameter | Specification |
|---|---|
| Manufacturer | Rockwell Automation |
| Model | 1786-TPYR |
| Module Type | Thermocouple Input |
| Channels | 8 |
| Input Range | -200°C to 1350°C |
| Accuracy | ±0.1% +1°C |
| Voltage | 24 VDC |
| Dimensions | 75 x 75 x 63.5 mm (2.95″ x 2.95″ x 2.5″) |
| Weight | 0.136 kg (0.3 lbs) |
Applications: Ideal for temperature-critical processes including furnace monitoring, reactor control, and HVAC systems. Compatible with ControlLogix 1756 chassis and pairs with complementary modules like 1756-IB32 digital input modules. Supports J, K, T, E, R, S, and B-type thermocouples for versatile industrial deployment.
Apex Automation Advantage: Since 2014, we’ve specialized in ready-to-ship industrial automation solutions. Our technical experts provide personalized pre-sales consultations and guaranteed 1-year post-sales support. Can’t find your specific model?
Contact us via WhatsApp for immediate assistance.
Pricing & Availability: Competitive quotes available upon request. Email technical specifications to anikaqx@gmail.com for volume discounts or custom configuration support.
