Technical Specifications
Inputs: 12 channels, 24V DC. Outputs: 8 channels, 24V DC, 0.5A. Isolation: 500V AC. Power dissipation: 2.5W. Operating temperature range: -40°C to +70°C.
Functional Features
12 digital inputs, 8 digital outputs. Opto-isolated channels. Per-channel status indicators. Output short-circuit protection. Hot-swap capability.
Application Scenarios
It expands discrete I/O capacity for MicroNet engine control, turbine control and industrial automation systems.
Performance Parameters
Input response: 1ms. Output switching: <1ms. Output current: 0.5A per channel. Operating temperature range: -40°C to +70°C.
Material Composition
Housing: flame-retardant plastic. PCB: FR-4. Outputs: MOSFET semiconductors. Connectors: gold-plated copper.
Structural Characteristics
MicroNet standard module, front panel LEDs, rear backplane connector, DIN rail mounting.
Working Principle
It acquires discrete input signals and drives output loads, communicating with the main controller over the MicroNet system bus.
Installation Requirements
Mount on MicroNet base. Connect to system bus. Wire field devices. Verify voltage.
Usage Notes
Do not exceed output ratings. Check status LEDs. Follow ESD procedures.
