Technical Specifications 24VDC auxiliary power, multi-channel digital signal transfer terminals. Operating temperature: -40℃ ~ +70℃.
Functional Features Digital command signal transfer, load terminal distribution, surge protection for output loops, status feedback.
Application Scenarios Start solenoid, auxiliary valve and alarm indicator driving circuits for engine control cabinets.
Performance Parameters Fast signal transmission, reliable terminal connection, built-in transient suppression.
Structural Characteristics DIN rail terminal board, channel status LED indicators.
Working Principle Control signals from the main digital module are transmitted to this terminal board, and the terminals switch the external load circuit according to command status.
Installation Requirements Separate signal wiring and high-current load wiring, follow the load rated parameter limits.
Usage Notes Do not overload the output terminals, cut off power before replacing the matched control module.
