Technical Specifications Compliant with Genius bus standard; Isolated bus interface; Supports multiple I/O nodes; DIN rack installation.
Functional Features Bidirectional bus data transmission; Communication fault detection; Module self-diagnosis; Status alarm output.
Application Scenarios Factory automation, assembly lines, material handling systems with distributed I/O architecture.
Performance Parameters High bus anti-interference capability; Real-time data refresh; Fault LED prompt.
Structural Characteristics Pluggable rack module, front diagnostic LEDs, bus cable terminals.
Working Principle Receive control commands from the PLC, distribute commands to each Genius I/O node, collect field digital and analog signals and upload back to the controller.
Installation Requirements Mount on GE Genius I/O rack; Use specified shield bus cable; Keep bus cable separated from high-voltage power cables.
Usage Notes Set unique station address for each bus node. Check bus termination resistance after wiring.
