Technical Specifications 6‑pin contact configuration, circular shell structure, rated contact current and voltage specification. Operating temperature ‑55 ℃ to +125 ℃, storage temperature ‑55 ℃ to +125 ℃, relative humidity 5%‑95% non‑condensing. Dust‑proof and moisture‑resistant mechanical design. Bayonet locking connection mechanism.
Functional Features Provides stable electrical connection for multi‑core field cables and equipment internal circuits. Adopts bayonet quick‑lock structure to guarantee anti‑vibration connection reliability. Shell provides mechanical protection for internal contact pins. Supports repeated plug‑and‑unplug operation for field maintenance work.
Application Scenarios Field‑cable connection spare component for GE turbine, drive and industrial control equipment, used in power plant, petrochemical and heavy‑industry site wiring maintenance.
Performance Parameters Low contact resistance, qualified anti‑vibration performance, stable electrical connection under harsh environmental conditions, long mechanical plug‑unplug service life.
Material Composition High‑strength metal connector shell. Copper‑alloy gold‑plated contact pins. High‑temperature‑resistant insulating plastic insert body. Bayonet locking mechanical parts. Sealing rubber gasket for dust‑proof and moisture‑proof.
Structural Characteristics Standard circular connector form factor. Bayonet locking ring locates on outer shell. Built‑in rubber sealing gasket realizes environmental sealing after mating. Cable tail supports cable strain‑relief fixation.
Working Principle Align plug and socket, rotate bayonet locking ring to complete locking mating. Gold‑plated contact pins realize conductive connection between cable side and equipment‑side circuits. Sealing gasket fills gap between plug and socket to block dust and moisture invasion. Bayonet locking structure resists vibration‑caused loose disconnection.
Installation Requirements Complete cable core crimping with corresponding contact pins. Assemble contact pins into connector insulating insert body. Mate plug and socket and rotate bayonet ring to lock completely. Verify locking state and pull‑resistant connection performance.
Usage Notes Do not exceed rated current and voltage specification. Keep contact pins clean and avoid scratch damage to gold‑plated surface. Guarantee bayonet locking is fully completed after mating. Prevent connector from long‑term immersion in liquid environment.
