Technical Specifications Multi‑channel digital input and digital output channels, DS3800 back‑plane bus interface, auxiliary DC power supplied by chassis back‑plane. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, relative humidity 5%‑95% non‑condensing. Conformal coating PCB protection. DS3800 chassis plug‑in mechanical structure.
Functional Features Acquires multi‑group digital status signals from field switches and auxiliary equipment. Completes signal level conversion and electrical isolation for field input signals. Converts digital commands from main processor into driving‑capable digital output signals for field devices. Provides hardware surge protection for each I/O channel. Supports channel‑wise fault self‑diagnosis and status feedback.
Performance Parameters Reliable digital signal electrical isolation performance, stable input‑output level conversion accuracy, fast channel fault detection response speed.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Signal isolation devices, level conversion integrated circuits, output driving components, surge protection elements. Gold‑plated DS3800 back‑plane edge connector. Front metal panel with status LED indicators and fixing hardware. Conformal protective coating layer.
Structural Characteristics Standard DS3800 chassis plug‑in board dimension. Rear gold‑plated edge connector mates with DS3800 system back‑plane bus. Front metal panel mounts status LED indicators and fixing screws. PCB layout realizes physical separation between field‑side signal circuit area and system‑side logic area.
Working Principle Board obtains operating power from DS3800 chassis back‑plane. Digital control commands from main processor go through driving‑isolation circuit and output to field‑side equipment. On‑board hardware monitors each I/O channel operating status and reports fault information to system.
Installation Requirements Insert DS3800HIOC into designated chassis slot, tighten front‑panel fixing screws. Restore chassis power supply, complete system power‑on self‑test and digital input‑output channel loop verification test.
Usage Notes Avoid mechanical scratch damage to conformal coating layer. Only install into compatible GE DS3800 control chassis.
