Technical Specifications Mark V back‑plane bus interface, on‑board memory components, multi‑function status LED indicators, auxiliary DC power supplied by chassis back‑plane. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, relative humidity 5%‑95% non‑condensing. Conformal coating PCB protection. Mark V plug‑in board mechanical form.
Functional Features Executes core turbine control logic algorithm for Mark V system. Completes data calculation, logic judgment and system‑wide bus resource management. Exchanges data with all peripheral functional boards via chassis back‑plane bus.
Application Scenarios Core spare‑part CPU board for GE Mark V gas and steam turbine control systems, used for power‑plant turbine‑control‑system maintenance and spare replacement.
Performance Parameters Stable logic‑calculation performance, reliable Mark V back‑plane bus management, large‑capacity on‑board data caching, consistent long‑term continuous‑running stability.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Main processor chip, memory integrated circuits, bus‑driving logic components. Gold‑plated Mark V back‑plane edge connector. Front‑panel metal bracket equipped with status LED indicators.
Structural Characteristics Standard Mark V chassis plug‑in board dimension. Rear gold‑plated edge connector interfaces with Mark V chassis back‑plane bus. Front metal panel mounts group of status LED indicators and fixing screws. High‑speed logic circuit area and signal interface area are reasonably partitioned on PCB layout.
Working Principle Processor board draws operating power from Mark V chassis back‑plane. After power‑on, it executes system initialization and hardware self‑diagnosis. Main processor chip runs turbine control application logic, exchanges data with all peripheral boards through back‑plane bus.
Installation Requirements CInsert DS200CPCAG1ABB board into designated CPU chassis slot, tighten front‑panel fixing screws. Restore chassis power supply, wait for system full initialization, check status LED indicators and complete system‑level function verification.
Usage Notes Anti‑static handling measures must be implemented. Protect conformal coating layer from mechanical scratch damage. Only work with compatible GE Mark V turbine control chassis.
