Technical Specifications Multi‑group mixed signal input‑output interfaces, internal system bus connector, auxiliary DC control power supply. Operating temperature 0 ℃ to +60 ℃, storage temperature ‑40 ℃ to +85 ℃, relative humidity 5%‑95% non‑condensing. Conformal coating PCB protection.
Functional Features Receives feedback signals from peripheral functional modules. Completes signal conditioning and level matching to fit main controller input specification. Buffers and forwards control commands from main logic unit to peripheral hardware. Provides hardware surge protection for signal channels and supports basic channel fault detection.
Application Scenarios Spare replacement circuit board for GE power conversion and industrial control equipment, applied for energy‑industry site maintenance and overhaul work.
Performance Parameters Stable multi‑channel signal conditioning accuracy, good anti‑interference performance, reliable bidirectional data‑buffer transmission capability.
Material Composition Multilayer glass‑fiber epoxy printed circuit board. Signal conditioning and buffer circuit components, surge protection devices. Multi‑pin plug‑in connectors.
Structural Characteristics Rectangular flat PCB layout. Pre‑drilled screw mounting holes for chassis bracket fixation. PCB layout separates analog‑signal area and digital‑logic area to reduce cross‑talk interference.
Working Principle Auxiliary DC power supplies on‑board circuit. Peripheral‑module feedback signals enter input terminals, pass through conditioning and buffer circuit and are transmitted to main control board. Control commands from main processor pass through buffer circuit and output to peripheral functional modules. Hardware protection circuit suppresses signal‑channel surge voltage.
Installation Requirements Fasten circuit board onto chassis mounting bracket with mounting screws. Fully insert and lock all plug‑in connectors. Restore auxiliary power supply, complete signal‑channel loop test and functional verification.
Usage Notes Avoid over‑range surge voltage applied to signal terminals.
