Technical Specifications Backplane power supply. MACRO fiber interface. Multi-axis real-time data transmission. Optical signal isolation. Operating temperature:0°C ~ +45°C.
Functional Features Fiber MACRO bus communication. Electrical isolation between master and slave. Real-time motion command and feedback transmission. Link fault diagnosis. LED status indicator.
Application Scenarios Long distance distributed multi-axis motion control, large gantry machine, production line remote axis control, high noise industrial site.
Performance Parameters Microsecond real-time communication cycle. Optical isolation resist electromagnetic interference. Operating temperature:0~+45°C.
Structural Characteristics 3U rack PCB, UBUS backplane connector, optical fiber transceiver port, onboard MACRO communication IC.
Working Principle Convert UMAC internal parallel bus data into optical signal, transmit over fiber to remote MACRO slave stations, receive optical feedback data and convert back to electrical signal for motion control.
Installation Requirements Install board into UMAC rack. Connect optical fiber according to MACRO ring topology. Check optical power and link status.
Usage Notes Protect fiber end face from dust and scratch. Maintain proper bending radius of optical cable.
