Technical Specifications 24V DC power supply. Redundancy support. Multiple I/O bus interfaces. Support PID, cascade and sequence control. Operating temperature:0°C ~ +60°C.
Functional Features Real-time process control calculation. Redundant operation capability. Control logic execution. Alarm and event logging. Communication with human-machine interface and I/O modules.
Application Scenarios Refinery, chemical, power generation, LNG plant, large-scale continuous process production control.
Performance Parameters Fast control cycle. High availability with redundant configuration. Operating temperature:0~+60°C.
Structural Characteristics Rack mounted controller unit, front status LED indicators, backplane bus connector, power and communication ports.
Working Principle Cyclically read process data from I/O modules, run configured control algorithms, calculate output values and send commands to I/O modules, upload alarm and trend data to operator stations.
Installation Requirements Mount in DCS control cabinet rack. Connect 24V DC power and control network cables. Complete controller configuration and download control program.
Usage Notes Backup control configuration regularly. Check network connection status for redundant system.
