Technical Specifications Pulse / direction output; Multi-axis pulse channel; Differential signal output; Rack pluggable.
Functional Features Pulse command generation; Position pulse output; Pulse signal monitoring; Channel fault detection.
Application Scenarios Automation equipment using pulse-type servo or stepper motors, such as cutting machines, positioning tables and small multi-axis machinery.
Performance Parameters High pulse output frequency; Stable differential signal transmission.
Structural Characteristics Rack plug-in module, front panel status LEDs, pulse signal terminal block and backplane connector.
Working Principle Receive position commands from MP2300 CPU module, convert motion commands into pulse and direction signals and send pulse signals to external servo or stepper drivers.
Installation Requirements Install on MP2300 backplane; Use shielded differential cable for pulse wiring; Keep away from high power cables.
Usage Notes Match pulse receiving mode with servo drive. Check pulse wiring to avoid signal interference.
