Technical Specifications Three-phase AC input. Analog / pulse command input. Incremental encoder feedback. Comprehensive fault protection. Operating temperature:0°C ~ +50°C.
Functional Features Position, speed and torque control. High overload capability. Motor overheat monitoring. Multiple fault alarm and status indication.
Application Scenarios Metal cutting machine, heavy material handling, large packaging machinery, automated press auxiliary axis.
Performance Parameters High continuous torque output, strong overload capacity. Operating temperature:0~+50°C.
Structural Characteristics Metal housing, high-current power terminals, motor connector, encoder and control signal interface, power conversion circuit.
Working Principle Receive motion command from upper controller, output variable frequency three-phase current to servo motor, read encoder feedback and execute closed-loop speed and position regulation.
Installation Requirements Install in ventilated control cabinet. Use thick gauge power cable for motor loop. Connect shielded encoder cable and protective ground.
Usage Notes Keep cooling fan clean. Avoid continuous long-time overload operation.
