Technical Specifications Three-phase AC power input. Analog or pulse command input. Incremental encoder feedback. Multiple protection functions. Operating temperature:0°C ~ +50°C.
Functional Features Position, speed and torque control mode. Servo motor closed-loop regulation. Overload, overheat, overcurrent alarm. Fault status indication.
Application Scenarios CNC machine auxiliary axis, packaging machinery, automated cutting equipment, material handling automation.
Performance Parameters Fast dynamic response, stable torque output. Operating temperature:0~+50°C.
Structural Characteristics Metal enclosure, power terminals, motor cable connector, encoder and control signal port, drive circuit board.
Working Principle Receive motion command from upper PLC or motion controller, output three-phase power to servo motor, read encoder position feedback and adjust output in real time for closed-loop motion control.
Installation Requirements Install in control cabinet with sufficient ventilation. Connect power, motor and shielded encoder cables. Set servo gain and axis parameters.
Usage Notes Ensure good cabinet ventilation to prevent overheating. Check grounding connection.
