Technical Specifications Voltage sensing: 100–480 V AC, 50/60 Hz; excitation output: up to 10 A DC; 24 V DC control supply; 10/100 Mbps Ethernet Modbus TCP/IP; RS-485 Modbus RTU; 16 analog I/O; operating temperature: -20°C to +70°C; IP40 enclosure.
Functional Features Automatic voltage regulation; power factor and VAR control; grid synchronization support; comprehensive electrical protection; Ethernet network connectivity; web server configuration; data logging.
Application Scenarios Industrial generator excitation control, parallel power plants, microgrid systems, combined heat and power facilities, remote monitoring applications.
Performance Parameters ±0.25% steady-state voltage regulation; fast transient load response; high-speed Ethernet communication; reliable protection accuracy.
Material Composition Steel enclosure, power electronics modules, microprocessor controller, Ethernet transceiver, voltage and current sensing transformers.
Structural Characteristics Panel mount housing; front Ethernet port and status indicators; rear power and signal terminal blocks; mounting ears for panel installation.
Working Principle Measures generator electrical parameters, executes digital voltage and power control algorithms, regulates excitation output, and provides Ethernet connectivity for remote monitoring and control.
Installation Requirements Mount on generator control panel; connect voltage, current and excitation wiring; connect Ethernet network cable; configure parameters via web interface or configuration tool.
