Technical Specifications PC/104 bus architecture; 32-bit RISC processor; 8 MB Flash memory, 4 MB SRAM; 8 analog inputs, 4 analog outputs; 16 digital I/O channels; RS-232, RS-485 communication interfaces; 5 V DC supply; operating temperature: -40°C to +85°C; conformal coating.
Functional Features Real-time control execution; configurable I/O mapping; PID control algorithms; fault diagnostic functions; non-volatile data logging; field-programmable firmware.
Application Scenarios Embedded engine control, turbine protection systems, industrial drive control, mobile equipment control, distributed control nodes.
Performance Parameters Fast control loop execution; high processing throughput; reliable operation over extreme temperature range; low power consumption.
Material Composition FR-4 circuit board, industrial grade semiconductor components, gold-plated PC/104 connectors, conformal acrylic coating.
Structural Characteristics PC/104 standard stackable form factor; pin header I/O connectors; mounting holes for stack fixation; compact low-profile design.
Working Principle Executes real-time control and protection firmware, acquires process signals via I/O channels, executes control algorithms, and outputs control signals to actuators and protection circuits.
