Technical Specifications 24VDC power supply, voltage and current sampling input, relay trip output. Operating temperature: -40℃ ~ +70℃.
Functional Features Electrical parameter measurement, threshold comparison, protection trip, fault record storage.
Application Scenarios Grid-connected generator electrical protection cabinets.
Performance Parameters Fast protection response speed and high measurement accuracy.
Structural Characteristics PCB board with gold-plated edge connector and fault trip indicator lamps.
Working Principle Collect generator voltage and current signals, trigger trip output when signals exceed preset protection thresholds.
Installation Requirements CT and PT wiring must follow specifications with reliable grounding.
Usage Notes Set protection parameters according to generator nameplate and grid requirements.
