Technical Specifications Integrated electrical measurement circuit, synchronizing logic, relay outputs, communication ports, 24V DC auxiliary power supply.
Functional Features Generator auto synchronizing, load sharing, mains paralleling, electrical fault protection, data logging and remote monitoring.
Application Scenarios Industrial power station, multiple diesel generator sets, critical backup power system.
Performance Parameters High accuracy measurement, fast protection response, stable load sharing between paralleled generators.
Structural Characteristics Panel mount controller, metal housing, local display, keypad and rear terminal block for field wiring.
Working Principle Collects generator and bus electrical signals, executes synchronization algorithm, controls engine governor and excitation to realize parallel operation and load distribution.
Installation Requirements Install on cabinet front panel, connect voltage and current transformers, engine control wiring.
Usage Notes High voltage present on PT/CT circuits. Do not modify protection parameters without professional calculation.
