Technical Specifications 24VDC power supply; analog or pulse command input; position feedback input; drive output for proportional actuator. Operating temperature: -40℃ ~ +85℃.
Functional Features Closed-loop valve position regulation; setpoint tracking; over-travel limit protection; internal fault self-diagnosis.
Application Scenarios Gas engine fuel metering valve, industrial burner and prime mover actuator control.
Performance Parameters Fast position tracking response, high positioning accuracy, strong anti-vibration performance.
Structural Characteristics DIN rail metal housing, pluggable multi-pin terminals, built-in drive circuit.
Working Principle The controller compares target position command with actual valve position feedback, calculates drive output signal, and adjusts actuator stroke to match the target opening. Real-time fault detection runs continuously during operation.
Installation Requirements Install close to the controlled valve; separate power cable and low-level signal cable.
Usage Notes Complete position calibration during commissioning; backup parameters before configuration modification.
