Technical Specifications 24VDC power supply; multi-channel analog and digital signal acquisition; built-in signal isolation circuit, wide industrial temperature range.
Functional Features High-speed signal sampling, signal filtering, channel fault detection, data transmission to main control module.
Application Scenarios CSC3 system supporting signal collection for gas engine and generator set control cabinet.
Performance Parameters High sampling precision, low signal noise, reliable long-distance signal transmission.
Structural Characteristics DIN rail mount module, pluggable wiring terminals, compact circuit assembly.
Working Principle Collect on-site pressure, temperature, switch signals, filter and isolate signals and transmit data to CSC3 main controller.
Installation Requirements Install close to field signal wiring, separate analog signal cable and power cable.
Usage Notes Check cable shielding grounding; inspect channel sampling data in routine maintenance.
