Technical Specifications 24VDC power supply, multi-channel discrete interlock input and protection output. Operating temperature: -40℃ ~ +70℃, programmable timer and threshold parameters.
Functional Features Pre-start interlock confirmation, automatic sequence control, parameter threshold protection, fault latch, alarm output.
Application Scenarios Gas engine automatic start control cabinets, small turbine sequence and protection systems.
Performance Parameters Accurate timing, strict interlock judgment, fast protection response, stable state transition.
Structural Characteristics Rack pluggable logic module, LED indicators for each sequence step and protection state.
Working Principle The module checks all preconditions before releasing start permission. It runs each step according to preset timing and logic, and locks the trip state when protection threshold is exceeded.
Installation Requirements Install inside the 9907 main control rack, ensure all interlock signal wiring is reliable and fixed.
Usage Notes Do not bypass protection interlock without authorization, modify sequence and protection parameters only according to unit manual.
