Technical Specifications 24VDC operating power supply; pulse speed signal input port; analog control output channel; built-in EMC filter circuit. Operating temperature: -40℃ ~ +85℃.
Functional Features Closed-loop PID speed governing; adjustable speed setpoint; overspeed monitoring and alarm; internal channel fault self-diagnosis.
Application Scenarios Medium and small gas engine and diesel generator speed governing control loops.
Performance Parameters Fast response to speed deviation, high governing precision, stable continuous operation under vibration environment.
Structural Characteristics Metal shielding housing, DIN rail mounting structure, pluggable terminal blocks.
Working Principle The module receives real-time speed pulse feedback, compares actual measured speed with preset setpoint value, calculates control output through built-in PID algorithm, and sends commands to the actuator driver to adjust fuel or gas valve opening.
Installation Requirements Install in sealed dust-proof cabinet; separate speed signal cable and high-power cable to avoid interference.
Usage Notes Backup governing parameters before modifying configuration; take anti-static protective measures during module replacement.
