Technical Specifications 24VDC power supply, analog command input and feedback signal collection. Operating temperature: -40℃ ~ +70℃, with signal isolation function.
Functional Features Fuel command signal conditioning, valve position feedback processing, signal isolation, fuel control loop fault detection.
Application Scenarios Land gas generator sets, industrial diesel engine fuel speed regulation systems, gas engine fuel valve control cabinets.
Performance Parameters Smooth signal output, small control hysteresis, stable closed-loop fuel regulation.
Structural Characteristics Compact pluggable PCB module, fuel loop status indicator lights.
Working Principle The module receives the fuel regulation command sent by the main control unit, processes and isolates the command signal and sends it to the fuel actuator, meanwhile collects the valve position feedback signal and returns it to the main controller.
Installation Requirements Install close to the fuel actuator wiring terminal, separate the control signal cable from high-power cables.
Usage Notes Check the zero point and span of the fuel loop after module replacement, avoid unstable combustion caused by signal deviation.
