Technical Specifications 24VDC power supply, compatible with vibration probe and velocity sensor signals. Operating temperature: -40℃ ~ +70℃, high-frequency signal sampling.
Functional Features Vibration signal amplification, high-frequency signal filtering, vibration value calculation, high vibration alarm, vibration data upload.
Application Scenarios Turbine shaft vibration monitoring, engine bearing vibration protection, generator set condition monitoring system.
Performance Parameters High sampling frequency, accurate vibration amplitude calculation, strong anti-high-frequency interference ability.
Structural Characteristics Pluggable PCB module, vibration channel status indicator lights, shielding shell design.
Working Principle The module receives weak high-frequency vibration signals from vibration sensors, filters out irrelevant frequency interference, calculates the vibration amplitude, and transmits the vibration data to the main controller for status judgment and protection.
Installation Requirements Install in a low-vibration area of the cabinet, use special shielded high-frequency vibration signal cables.
Usage Notes The vibration probe wiring cannot be shared with power lines, and the sensor and module need to be calibrated as a set.
