Technical Specifications 24VDC power supply, voltage and current sampling input, relay trip output. Operating temperature: -40℃ ~ +70℃.
Functional Features Electrical parameter measurement, over-limit judgment, protection trip action, fault record storage.
Application Scenarios Grid-connected generator set electrical protection cabinet.
Performance Parameters Fast protection response speed and high measurement accuracy.
Structural Characteristics PCB with gold-plated edge connector and trip fault indicator lights.
Working Principle Collect generator voltage and current signals, and trigger trip output when exceeding the preset protection threshold.
Installation Requirements CT and PT wiring must comply with specifications and be reliably grounded.
Usage Notes Set protection thresholds according to generator nameplate parameters and grid requirements.
