Technical Specifications 24VDC power supply, multi-channel discrete event input, high precision internal clock. Operating temperature: -40℃ ~ +70℃.
Functional Features Event signal capture, microsecond level time stamping, event data storage, event uploading to upper monitoring system.
Application Scenarios Generator fault event recording, prime mover trip sequence analysis, power plant SOE recording.
Performance Parameters High time synchronization accuracy, fast event capture speed, large event storage capacity.
Structural Characteristics Rack pluggable module, communication and fault status LED indicators.
Working Principle Once the input signal state changes, the module immediately marks the event with synchronized time stamp, stores the event record and transmits the record to the main controller and monitoring system.
Installation Requirements Connect to system time synchronization signal, adopt independent wiring for event input signals.
Usage Notes Regularly synchronize the internal clock, back up event records before clearing.
