Technical Specifications 24VDC power supply; multi-range analog signal input and output; input and output galvanic isolation. Operating temperature: -40℃ ~ +70℃.
Functional Features Analog signal amplification and conditioning; electromagnetic noise filtering; overrange protection; ground loop interference elimination.
Application Scenarios Turbine, gas engine and genset pressure, temperature and displacement signal acquisition loops.
Performance Parameters Low signal distortion, high isolation voltage, stable signal transmission under EMI environment.
Structural Characteristics DIN rail metal housing, pluggable screw terminals, integrated isolation circuit.
Working Principle Raw sensor analog signal enters the module, passes filtering, amplification and isolation circuit, then converted standard signal is sent to main control board.
Installation Requirements Install close to field sensors; separate analog signal wiring and high-current power cables.
Usage Notes Calibrate signal range before putting into service; avoid overvoltage input.
