Technical Specifications Matched with 8915 series modules, screw type terminal connection. Operating temperature: -40℃ ~ +70℃.
Functional Features Analog signal terminal distribution, signal filtering, convenient module hot-swap maintenance, wire break inspection.
Application Scenarios Pressure, flow and level analog signal wiring for prime mover control and generator governing systems.
Performance Parameters Low signal transmission loss, stable terminal contact, good anti-interference performance.
Structural Characteristics DIN rail mounted PCB board, dense screw terminals and matching module connector.
Working Principle Field analog cables are connected to the screw terminals of this board. Signals are transmitted through internal circuits to the connector and then sent to the analog input module.
Installation Requirements Install close to the control module, use shielded twisted-pair cables for analog signal wiring.
Usage Notes Tighten terminal screws after wiring, check terminal corrosion regularly in humid environments.
