Technical Specifications 24VDC power supply; position sensor input; standard analog signal output; signal filtering and surge protection. Operating temperature: -40℃ ~ +70℃.
Functional Features Position signal acquisition and conditioning; noise filtering; galvanic isolation; standard analog signal conversion.
Application Scenarios Engine fuel actuator and gas metering valve closed-loop control systems.
Performance Parameters High measurement linearity, low signal drift, stable output under industrial electromagnetic interference.
Structural Characteristics Compact metal housing, DIN rail installation, pluggable wiring terminals.
Working Principle Raw displacement signal from actuator position sensor enters the transmitter. After filtering, isolation and conversion, standard analog position signal is transmitted to governor controller.
Installation Requirements Install near the actuator; separate low-level signal cable and high-power drive cable.
Usage Notes Calibrate zero and full-scale range during commissioning; inspect wiring insulation regularly.
