Technical Specifications 24VDC power input; integrated position feedback; high torque mechanical output structure. Operating temperature: -40℃ ~ +85℃.
Functional Features High-torque linear stroke adjustment; real-time position feedback; stroke limit protection; overload and stall protection.
Application Scenarios Heavy-duty diesel engine, marine propulsion engine and large generator set fuel control.
Performance Parameters High output torque, fast response speed, good repeatability, stable operation under strong vibration.
Structural Characteristics Thick metal housing, reinforced gear transmission, built-in position sensing component, separated wiring terminals.
Working Principle The internal electromagnetic drive assembly converts control current into mechanical rotary motion, converted to linear stroke to adjust fuel rack. Position sensor feeds back actual stroke signal to controller for closed-loop adjustment.
Installation Requirements Solid mounting base; properly adjust linkage clearance; use shielded twisted pair for feedback signal wiring.
Usage Notes Avoid excessive mechanical preload on linkage; inspect coil insulation and transmission wear during overhaul.
