Technical Specifications 24VDC power supply, voltage and frequency signal input, pulse output. Operating temperature: -40℃ ~ +70℃.
Functional Features Voltage, frequency and phase detection, automatic synchronization, closing output.
Application Scenarios Grid-connected generator set control cabinet.
Performance Parameters High synchronization precision, stable closing action.
Structural Characteristics PCB board with gold-plated edge connector, synchronization indicator.
Working Principle Detect generator and bus voltage, frequency and phase angle, send closing pulse when synchronization condition is satisfied.
Installation Requirements Voltage sampling wiring must be correct, check phase sequence.
Usage Notes Set synchronization window according to grid standard.
