Technical Specifications 24VDC power supply, voltage and current signal input, relay trip output. Operating temperature: -40℃ ~ +70℃.
Functional Features Electrical parameter monitoring, threshold comparison, protection trip, fault record.
Application Scenarios Generator set electrical protection cabinet.
Performance Parameters Fast protection action, high measurement precision.
Structural Characteristics PCB board with gold-plated edge connector, trip indicator lamp.
Working Principle Collect generator voltage and current signals, judge whether it exceeds the limit, output trip signal when fault occurs.
Installation Requirements CT/PT wiring strictly follow specification, reliable grounding.
Usage Notes Set protection threshold according to generator parameter.
