Technical Specifications 24VDC power supply, voltage and current sampling input, relay trip output. Operating temperature: -40℃ ~ +70℃.
Functional Features Electrical parameter measurement, over-limit judgment, protection trip, fault record storage, alarm output.
Application Scenarios Grid-connected generator set electrical protection cabinet.
Performance Parameters Fast protection response speed, high measurement accuracy.
Structural Characteristics PCB with gold-plated edge connector, trip and fault indicator lights.
Working Principle Collect voltage and current signals of the generator, compare with preset protection thresholds, and trigger trip output when a fault occurs.
Installation Requirements CT and PT wiring must comply with specifications, ensure reliable grounding.
Usage Notes Set protection thresholds according to generator nameplate parameters and grid requirements.
