Technical Specifications 24VDC power supply, voltage and current signal input, relay trip output. Operating temperature: -40℃ ~ +70℃.
Functional Features Electrical parameter measurement, threshold judgment, protection trip action, fault record storage.
Application Scenarios Generator set electrical protection cabinet.
Performance Parameters Fast protection response and high measurement accuracy.
Structural Characteristics PCB with gold-plated edge connector and trip status indicator.
Working Principle Collect generator voltage and current signals, trigger trip output when exceeding the set protection threshold.
Installation Requirements CT and PT wiring must comply with specifications and be reliably grounded.
Usage Notes Set protection parameters according to generator nameplate data.
