Technical Specifications 24VDC power supply, frequency signal input, digital communication output. Operating temperature: -40℃ ~ +70℃.
Functional Features Pulse signal shaping, speed calculation, overspeed alarm, signal fault detection.
Application Scenarios Turbine, engine speed measuring system.
Performance Parameters High speed resolution, strong anti-pulse interference.
Structural Characteristics PCB board with gold-plated edge connector, signal conditioning circuit.
Working Principle Shape the pulse signal from speed sensor, calculate rotation speed and transmit data to main controller.
Installation Requirements Use shielded wire for speed signal wiring, avoid parallel with power cable.
Usage Notes Check sensor air gap and signal amplitude before commissioning.
