Technical Specifications Supply voltage: 24 V DC; Analog input: 4–20mA; Digital input and relay output; Communication: internal system bus; Operating temperature: -40 °C to +85 °C; Enclosure: IP30.
Functional Features Multi-channel analog signal acquisition; digital status input; relay output for alarms; bus communication with main controller.
Application Scenarios Steam turbine and gas turbine control system, industrial power plant DCS local signal collection.
Performance Parameters Analog measurement accuracy: ±0.1% FS.
Material Composition Metal module housing; signal conditioning PCB; relay components; bus connector.
Structural Characteristics Rack mount module; front terminal block for field wiring; backplane bus connector.
Working Principle The module samples analog and digital field signals, transmits data to main controller over backplane bus, and executes relay output commands sent from main controller.
Installation Requirements Insert into system rack; connect field sensor wiring to terminal block; verify backplane bus connection.
