Technical Specifications Supply voltage: 24 V DC; Analog input: 4–20mA load signal; Communication: Modbus RTU; Operating temperature: -40 °C to +85 °C; Enclosure: IP30.
Functional Features Generator load sharing; parallel synchronization assistance; load deviation correction; network monitoring.
Application Scenarios Multiple gas/diesel generator parallel power plant, cogeneration islanded power system.
Performance Parameters Load sharing accuracy: ±1% of rated load.
Material Composition Metal housing; signal acquisition PCB; isolated analog terminals.
Structural Characteristics DIN rail mounted unit; analog input/output terminals and communication terminals.
Working Principle Collect load signal from each generator, calculate load deviation between units, send correction signal to each governor to adjust fuel and balance load across paralleled gensets.
Installation Requirements Mount on DIN rail; connect load signals and communication bus; configure unit rated power and load sharing parameters.
