Technical Specifications 24VDC power supply; isolated signal input and output; built-in surge and overvoltage protection circuit. Operating temperature: -40℃ ~ +70℃.
Functional Features Actuator position signal conditioning; galvanic signal isolation; noise filtering; signal conversion to standard analog value.
Application Scenarios Diesel and gas engine actuator closed-loop control cabinets.
Performance Parameters Low signal distortion, strong noise suppression, stable output signal under industrial electromagnetic interference.
Structural Characteristics DIN rail metal housing, pluggable screw terminals, onboard EMC filter components.
Working Principle Raw position signal from actuator enters the module, noise is filtered and signal is isolated and converted into standard analog signal, then transmitted to governor controller for closed-loop calculation.
Installation Requirements Install close to actuator; separate weak signal cable and high-power drive cable; properly ground shielding layer.
Usage Notes Check signal calibration regularly; avoid over-range input to prevent circuit damage.
