Technical Specifications 24VDC control signal; built-in high-resolution position feedback sensor; wide working temperature range; high mechanical positioning resolution.
Functional Features Precise linear stroke adjustment; real-time position feedback output; mechanical stroke limit protection; built-in fault detection and alarm function.
Application Scenarios Gas engine and diesel engine fuel control systems, gas pipeline flow regulation loops.
Performance Parameters Rapid stroke response; high positioning repeatability; low mechanical hysteresis for accurate flow regulation.
Structural Characteristics Integrated rugged metal housing; internal electromagnetic coil and precision transmission mechanism; dedicated wiring terminals for control signal and position feedback.
Working Principle Upon receiving control signal, the internal coil drives the transmission mechanism to move the valve spool and change valve opening. The built-in position sensor converts mechanical stroke into electrical signal and sends real-time position value back to controller to realize closed-loop adjustment.
Installation Requirements Mount firmly on the valve body; ensure mechanical connection is smooth without jamming or sticking; adopt shielded cable for position feedback signal wiring.
Usage Notes Perform full-stroke calibration and zero-point adjustment during system commissioning; inspect mechanical clearance and lubrication condition regularly.
