Technical Specifications 24VDC power supply; pulse speed input; analog control output; configurable governing parameters. Operating temperature: -40℃ ~ +85℃.
Functional Features Closed-loop PID speed regulation; speed setpoint adjustment; overspeed alarm and monitoring; internal fault self-check.
Application Scenarios Stationary genset and industrial engine speed governing control loops.
Performance Parameters Fast response for load change, high speed control precision, stable operation under vibration.
Structural Characteristics Metal shielding enclosure, DIN rail mounting, pluggable terminal blocks.
Working Principle The module receives real-time speed pulse signal from magnetic pickup, compares actual speed with setpoint, calculates control output through PID algorithm to adjust actuator stroke and fuel flow.
Installation Requirements Install in sealed control cabinet; shielded twisted pair for speed signal wiring.
Usage Notes Backup governing parameters before modification; anti-static protection during replacement.
