Technical Specifications Output: variable reluctance sine wave; Frequency range:0~10kHz; Operating temperature:-40 °C ~ +150 °C; Thread:3/4-16 UNF; Housing:416 stainless steel.
Functional Features High signal output amplitude; passive sensor; vibration resistant; suitable for long wiring distance.
Application Scenarios Engine with long cable routing, remote speed measurement, gas turbine speed detection, overspeed protection system.
Performance Parameters Output amplitude:>1.0V peak; Air gap:0.25~1.25 mm.
Material Composition Stainless steel housing; high strength permanent magnet; multi-turn induction coil; shielded cable.
Structural Characteristics Threaded cylindrical probe; hex wrench surface; shielded signal cable.
Working Principle Variable reluctance principle. Gear tooth passing the probe changes magnetic flux, induces high amplitude AC sine wave signal proportional to rotating speed.
Installation Requirements Install on gear tooth mounting boss; adjust air gap; lock nut; route shielded cable to governor controller.
Usage Notes Keep cable away from high voltage ignition wires; check shielding continuity regularly.
