Technical Specifications Input: 18–32 V DC (24 V nominal); outputs: +5 V DC at 1 A, +24 V DC at 0.5 A; total power: 17 W; overcurrent, overvoltage and short-circuit protection; operating temperature: -40°C to +85°C; IP20 enclosure; MTBF > 400,000 hours.
Functional Features Dual regulated DC outputs; wide input voltage range; comprehensive fault protection; low output ripple; reverse polarity protection; power good signal.
Application Scenarios Low-power control circuits, sensor power supply, industrial instrumentation, small control system power distribution.
Performance Parameters ±1% output regulation; low ripple noise; fast transient response; high efficiency.
Material Composition Metal shielded case, DC-DC converter circuit, filter capacitors, insulated output terminals.
Structural Characteristics Compact rack plug-in form; front status LED; rear input and output terminal block; backplane compatible.
Working Principle Converts 24 V DC input into regulated 5 V and 24 V DC outputs through isolated DC-DC conversion, with feedback control and protection circuitry.
Installation Requirements Install in control rack; connect input DC supply with fuse protection; verify output voltages before connecting load; implement system grounding.
