Technical Specifications 24VDC power supply; voltage/current signal input; multi-channel digital output; -40℃ ~ +85℃.
Functional Features Overvoltage/undervoltage protection, overcurrent protection, fault alarm, trip interlock, event logging.
Application Scenarios Industrial generator set power control and protection cabinets.
Performance Parameters Fast fault detection, reliable trip action, stable signal sampling.
Structural Characteristics DIN rail mounted metal casing, pluggable terminals for voltage and current signal.
Working Principle Collect generator voltage and current signals continuously, compare with protection thresholds and trigger trip when abnormal conditions are detected.
Installation Requirements Install in generator control cabinet; use shielded cable for AC sampling signals.
Usage Notes Verify CT/PT wiring before commissioning; test protection function periodically.
