Technical Specifications Supply voltage:24 V DC ±10%; Communication:DeviceNet 2.0; Operating pressure:0.3–8 bar(g); Operating temperature:-30 °C ~ +115 °C; Enclosure:IP65.
Functional Features Precision low flow trim; DeviceNet digital communication; LVDT closed-loop feedback; remote parameter configuration and fault diagnosis.
Application Scenarios Small gas engine network control, micro cogeneration unit, pilot gas digital control, low-power gas genset.
Performance Parameters Flow linearity:±2.5% FS; Repeatability:±1.2% FS; Bus update cycle:20 ms.
Material Composition Aluminum valve body; precision stainless steel low flow trim; FKM seals; miniature LVDT; DeviceNet electronic module.
Structural Characteristics Inline low flow valve body; precision small orifice trim; top solenoid and DeviceNet electronic assembly.
Working Principle DeviceNet master sends opening command. LVDT feeds back plunger position, controller adjusts solenoid current to precisely control small gas flow through special low flow trim.
Installation Requirements Install inline; install fine upstream filter; connect DeviceNet bus and power; set MAC ID and calibrate low flow section.
